-16AN Female Weld Bung - 6061 Aluminum

SKU 26042
Availability:
Only 24 left!
Original price $ 0
Original price $ 11.00 - Original price $ 11.00
Original price
Current price $ 11.00
$ 11.00 - $ 11.00
Current price $ 11.00

Product Dimension Info

Detailed product dimensions can be found on the main product page. If you need further assistance with product dimensions please email us at your convenience.

Description

The Ace Race Parts brand of -16AN Female ORB AN Weld Bungs are precision CNC machined from 6061-T6 Aluminum and feature a stepped design for added weld strength and durability. Our line of Female ORB Weld Bungs are available in sizes ranging from -4AN to -20AN and are suitable in high pressure applications, like fuel systems, fuel cells, oil tanks, and other custom applications.

FEATURES

  • ORB (O-Ring Boss) Connection
  • Reusable SAE Straight Thread
  • Precision CNC Machined from 6061-T6 Aluminum
  • Capable of Handling High Pressure Applications
  • Suitable for Fuel Systems (E85 Compatible) and more!
DETAILS
Material Type
6061-T6 Aluminum
Bung Type
Weld Bung; Female AN
Connection Type
Connection Type
37° AN Flare connection types seal with the flare. ORB connection types seal with an o-ring.
O-Ring Boss (ORB)
Thread Type
Female - Straight Thread
DIMENSIONS
AN Size
-16AN
SAE Thread Size
SAE Thread Size
The thread size and pitch (threads per inch) of the weld bung.
1-5/16"-12
Shoulder Diameter
Shoulder Diameter
The overall diameter of the largest part of the weld bung.
1.889"
Body Diameter
1.635"
Height
Height
The overall height of the weld bung.
0.669"
ADDITIONAL INFORMATION
Product Title
-16AN Female Weld Bung - 6061 Aluminum
SKU / Part Number
26042
Brand / Manufacturer
Ace Race Parts
On-Hand Quantity
On-Hand Quantity
On-hand quantity stocked at our Washington warehouse.
24
UPC Code
840458205707
Product Warranty
Product Warranty
Our detailed product warranty policy can be found here: https://support.aceraceparts.com/en-US/warranty-policy-30022
1-Year Limited Warranty
